ESD Flat PCB Linking Conveyor Width Adjustment In SMT Assembly Equipment

ESD Flat PCB Linking Conveyor Width Adjustment  In SMT Assembly Equipment
ESD Flat PCB Linking Conveyor Width Adjustment  In SMT Assembly Equipment

Large Image :  ESD Flat PCB Linking Conveyor Width Adjustment In SMT Assembly Equipment

Product Details:
Place of Origin: China
Brand Name: HSTECH
Certification: CE
Model Number: HS-460-CY
Payment & Shipping Terms:
Minimum Order Quantity: 2 sets
Price: Negotiable
Packaging Details: Wooden case
Delivery Time: 5~7 days
Payment Terms: T/T, Western Union, MoneyGram, D/P
Supply Ability: 500 pcs per month
Detailed Product Description
Product Name: PCB Linking Conveyor Material: Stainless Steel
Color: White Transport Belt: ESD Flat Belt
Condition: New Voltage: 1P AC 110V/220V 50/60HZ
Warranty: 1 Year After-sales Service Provided: Online Support
High Light:

smt production line equipment

,

pcb loader and unloader

ESD Flat Width Adjustment PCB Linking Conveyor for SMT Production Line



Features



1, Modular design.

2, Iron square tube framwork, powder coating on surface.

3, Variable speed control function.

4, Sturdy structural design improves the stability of the equipment.

5, Use stainless steel screw,smooth and parallel width adjustment.

6, Compatible SMEMA standard.



Specification



Model HS-460-CY
Power Supply AC220V or AC110V 50/60Hz
PCB Size 50*50~500*460mm
Width adjustment Hand shake
PCB Direction Left to right or right to left
Transmission Height 900 ± 20 mm
Transmission Speed 0.5-20 meters per minute adjustable
Track fixed side front side fixed( or back side fixed for option)
Machine Length 0.5M/0.6M/0.8M/1M/1.5M
Options Light,Fan,Magnnifying,Cover,Inspection
